This Wideband 700-1000MHz Wireless Power Amplifier Jammer Module is a wideband wireless power amplifier jammer designed to disrupt wireless communication signals within the 700 - 1000MHz frequency range. It is specifically engineered for various applications where the control or prevention of unauthorized wireless communication is required, such as in security-sensitive areas like military bases, government facilities, prisons, and during large-scale events to maintain order and security. The quality of the modules produced by RX is guaranteed, and their excellent performance and good use effect make them popular with customers.
This Wideband 700-1000MHz Wireless Power Amplifier Jammer Module is capable of delivering a significant amount of output power 100W, this high output power enables it to generate strong interference signals that can overpower and disrupt wireless signals over a considerable distance, thereby expanding its interference range. The digital control interface allows for flexible configuration of the jammer module.
No. |
Item |
Data |
Unit |
1 |
Frequency |
1000-1700 |
MHz |
2 |
Test voltage |
28 |
V |
3 |
Current |
4.2 |
A |
4 |
Output |
100 |
W |
5 |
Gain |
47 |
dB |
6 |
Output stability |
1 |
dB |
7 |
Connector |
SMA / Female |
|
8 |
Output connector VSWR |
≤1.30 (No power and VNA test) |
|
9 |
Power supply wire |
Red+Black+Enable wire |
|
10 |
Enable Control |
High ON Low Off |
|
11 |
Out shell Size |
201*105*21mm |
mm |
12 |
Mount hole |
100*196 |
mm |
13 |
Weight |
1029 |
g |
14 |
Work Temperature |
-40~+65 |
℃ |
15 |
Out shell material |
Aluminum |
|
16 |
Vibration need |
Car loadOK |
