2.4G 50W Anti Drone Signal Jammer Module

Find a huge selection of 2.4G 50W Anti Drone Signal Jammer Module, phone signal jammer, signal jammer module from China at Rongxin. Provide professional after-sales service and the right price, looking forward to cooperation.Rongxin anti drone signal jammer module is widely applied to the signal jammer assembly .This RF module is protected with an aluminum alloy out shell, with fast heat dissipaiton.

Send Inquiry

Product Description

Rongxin 2.4G 50W Anti Drone Signal Jammer Module Introduction

Rongxin is a large-scale 2.4G 50W Anti Drone Signal Jammer Module manufacturer and supplier in China.Hot sale quality Rongxin 2.4G 50W anti drone signal jammer module with low price made in China.Rongxin 2.4G 50W anti drone signal jammer module is a wireless information security module dedicated to 2400-2500MHz signals. This module has the features of high average output power, good in-band flatness, and small offset between upper and lower side bands.

Rongxin 2.4G 50W Anti Drone Signal Jammer Module Specification

In Index	Numerical value			Unit	Note
In Index	Min	Typical	Max	Unit	Note
Signal frequency	2400		2500	MHz
Output power	46.5	47	47.5	dBm
Band flatness		1		dB
Work current		3.3		A
Work voltage	24		28	V
Work efficiency		50		%
Thermally offset of upper band		5		MHz	Module surface temperature: 85°C
Thermally offset of bottom band		5		MHz	Module surface temperature: 85°C
Weight	0.26kg
Dimension	1545120mm
Note: 1. The positive terminal is connected to the core capacitor, and the negative terminal is connected to the edge of the shell. 2. Connect the power when the antenna is connected; otherwise, the module may be damaged. Before powering on the module, check whether the power voltage is within the allowable range.

Rongxin 2.4G 50W Anti Drone Signal Jammer Module Feature

* With temperature protection and VSWR function, which can avoid damages from misoperation , extend the product life .

* With Software control interface ( Optional)

* It is widely applied to the RF analog signal jammer assembly such as anti drone signal jammer, phone signal signal jammer, GPS signal jammer, WIFI jammer, etc.

* Small size and light weight

* High reliability and durability

* High and low level current can be controlled by switch
