Signal Power Amplifier Module for Anti Drone

This is a high-quality signal power amplifier module specially designed for anti-UAV applications. 50W High Quality Signal Power Amplifier Module for Anti Drone has a power output capacity of 50W. It aims to effectively interfere with the communication links and control signals of drones by enhancing the power of interference or blocking signals, thereby preventing drones from illegally invading specific airspace and ensuring the safety of sensitive areas. RX is a professional module manufacturer and supplier in China, and their excellent performance and good use effect make them popular with customers.

Send Inquiry

Product Description

50W High Quality Signal Power Amplifier Module for Anti Drone

This module has a power output of 50W, which can significantly enhance the relevant signal strength for anti-drone use. Whether it is interfering with commonly used communication bands for drones, such as 2.4GHz, 5.8GHz, etc., or blocking specific control channels, the powerful power can ensure that the interference signal has sufficient strength within a certain range. It can be used in military, government, large events.

Product specification

No.	Item	Data	Unit
1	Frequency	400-2700	MHz
2	Test voltage	28	V
3	Current	4.1	A
4	Output	50	W
5	Gain	47	dB
6	Output stability	1	dB
7	Connector	SMA / Female
8	Output connector VSWR	≤1.30 (No power and VNA test)
9	Power supply wire	Red+Black+Enable wire
10	Enable Control	High ON Low Off
11	Out shell Size	1455320	mm
12	Mount hole	139*48	mm
13	Weight	286	g
14	Work Temperature	-40~+65	℃
15	Out shell material	Aluminum
16	Vibration need	Car load OK
