High Gain Fiberglass Omni Directional Signal Jammer Antenna

Rongxin Communication Co., Ltd. is China manufacturer and supplier who mainly produces anti drone device, drone jammer module, anti with many years of experience. Hope to build business relationship with you.Rongxin high gain fiberglass omni directional signal jammer antenna is a customized high gain omni directional antenna for drone jammer, phone jammer, wifi jammer, GPS jammer, etc.Customers can choose the antenna according to their needs. For example, the antenna used by the amplifier to receive outdoor signals is generally a directional antenna, while the antenna used for indoor transmission is an omnidirectional antenna. Antennas with different functions have different uses.Antenna can complete the transmission and reception of signals, for signal booster antennas can receive signals as well as transmit signals, as a shield antenna is for signal transmission.

Send Inquiry

Product Description

Rongxin High Gain Fiberglass Omni Directional Signal Jammer Antenna Introduction

High quality fiberglass omni directional signal jammer antenna made in China. Rongxin is a signal jammer manufacturer and supplier in China.Rongxin high gain fiberglass omni directional signal jammer antenna is widely applied the signal jammer field, especially those long range jammer project such as military drone jammer, anti bomb vehicle mount jammer, fixed base station drone jammer, etc.We offer the customized frequency OMNI directional fiberglass antenna for the phone shield device, anti drone system, etc. including the fiberglass omni directional antenna, directional panel antenna, base station antenna, etc. You can rest assured to buy customized fiberglass omni directional signal jammer antenna from us. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time!

Rongxin High Gain Fiberglass Omni Directional Signal Jammer Antenna Specification

* Customized options avaiable: car anti-shock antenna, fixed antenna,etc.
* Frequency is customized

Electical specification
Frequency Range	1150-1350 MHz/Antenna 1 1520-1620 MHz/Antenna 2 2400-2500 MHz/Antenna 3&4 5150-5850 MHz/Antenna 5&6
5Gain(dBi)	8±1dBi
VSWR	≤1.5
Polarization	Vertical
Horizontal Beamwidth(0º)	H: 360º
Vertical Beamwidth(0º)	V: 15±5º/7±5º
Input Impedance（Ω）	50Ω
Maximum input power(W)	100W
Inpur connector type	N-K
Lightning Protection	DC Ground
Mechanical specification
Dimensions(Height/Diameter)	600*40mm
Antenna weight	0.74Kg
Rated Wind Velocity	60m/s
Operational Humidity	10- 95%
Out shell Color	Black
Out shell material	Fiberglass
Operating temperature(ºC)	-30～70º
Installation Method	Connect with the counter body or antenna lifter
Vertical Direction		Horizontal Direction
