1000-1700MHz WideBand 50W RF Power Amplifier Module for Drone

This is a RF power amplifier module designed specifically for drones. It operates in the 1000-1700MHz frequency band and has a high power output capability of 50W. 1000-1700MHz WideBand 50W RF Power Amplifier Module for Drone allows the module to adapt to a variety of drone communication systems with different frequencies, making it highly versatile and eliminating the need for frequent replacement for drones with different frequencies. Rx as a professional module manufacturer, you can rest assured to buy module from our factory and we will offer you the best after-sale service and timely delivery.

Send Inquiry

Product Description

This module uses advanced RF amplification technology and high-quality electronic components, which can maintain stable performance during long-term operation. Whether in high temperature, low temperature or other harsh environmental conditions, it can ensure the reliability of drone communication. It can use in prison, government, school and so on. The power amplifier module can ensure the stable and reliable communication link between the UAV and the ground control station.

1000-1700MHz WideBand 50W RF Power Amplifier Module for Drone specification

No.	Item	Data	Unit
1	Frequency	1000-1700	MHz
2	Test voltage	28	V
3	Current	4.2	A
4	Output	50	W
5	Gain	47	dB
6	Output stability	1	dB
7	Connector	SMA / Female
8	Output connector VSWR	≤1.30 (No power and VNA test)
9	Power supply wire	Red+Black+Enable wire
10	Enable Control	High ON Low Off
11	Out shell Size	1778426mm	mm
12	Mount hole	78*170	mm
13	Weight	772	g
14	Work Temperature	-40~+65	℃
15	Out shell material	Aluminum
16	Vibration need	Car loadOK
